Nominal wattage	600.00 W
Nominal voltage	330 V
Mains frequency	0/50/60 Hz
Nominal current	3000mA / 1250 mA
Max. number of luminaires per miniature circuit breaker B16	2
Max. number of luminaires per miniature circuit breaker C16	3
Power factor λ	> 0.94
Total harmonic distortion	< 20 %
Protection class	I
Operating mode	External LED driver

Luminous flux	92600 lm
Luminous efficacy	151 lm/W
Color temperature	4000 K
Light color (designation)	Cool White
Color rendering index Ra	70
Standard deviation of color matching	5 sdcm
Low flicker	Yes
Flickering metric (Pst LM)	<1
Stroboscope effect metric (SVM)	<0.4
Photobiological safety group acc. to EN62778	RG2
Beam angle	45 °

Product color	Gray
Housing color	Gray
RAL-Number	RAL 9006
Body material	Aluminum
Cover material	Glass
Light emitting surface material	Glass
Glow Wire Test according to IEC 60695-2-12	650 °C
Mercury content	0.0 mg

Ambient temperature range	-40…+50 °C
Temperature range at storage	-40…+85 °C
Type of connection	CABLE, 5-POLE
Type of protection	IP66/IP66
Protection class IK (shock resistance)	IK08
Corrosion resistance class acc. to EN 12944	C5
Dimmable	No
Mounting location	Wall, Pole, Floor
Application environment	Outdoor
Adjustable	Yes
With light source	Yes
Replaceable light source	No

¹⁾ t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)

Standards	CE, CB, ENEC, UKCA, EAC, EPD
Luminaire with limited surface temperature, "D sign"	No
Ball shot safe	Yes
Replaceable light source (EPREL)	Not replaceable

Product remark

Available from December 2025

Minimum rate of recycled material in packaging	80 % ¹⁾
Minimum percentage of recycled content in the product	0 % ¹⁾
Product recyclability	Mostly recyclable product ¹⁾
Packaging recyclability	Mostly recyclable packaging ¹⁾
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage	No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage	Yes
List of substances of very high concern in concentrations greater than 0.1% in mass percentage	Lead (7439-92-1)

¹⁾ According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits

For extreme temperatures: –40 °C to +50 °C (outdoors), up to +40 °C (indoors)
Robust and weatherproof: IP66 / IK08, C5-M corrosion protection for harsh environments
Ball-impact safe: tested to DIN 18032-32, ideal for sports halls
Effective thermal management: up to 115,000 operating hours lifespan
Safety rope: included as standard for fall protection

Areas of application

Large stadiums & arenas: homogeneous indoor/outdoor lighting, ideal for TV applications
City centers/parks: suitable for large squares, monuments, events, or open-air cinemas
Ports/logistics: lights deep & wide areas, ideal with C5 corrosion protection
Industrial sites: wide-area safety lighting for factories and power plants
Motorsport venues: various lenses, illuminating long track sections for TV use

Product features

Equipment / Accessories

Safety rope for luminaire included in all versions
Power supply unit is not included; luminaire head and and driver box sold separately
Light modules pre-wired for direct connection in the driver or FL MAX CONNECTOR BOX

Safety advice

All electrical connections must be made by a qualified person.
The external flexible cable or cord of this luminaire cannot be replaced; if the cord is damaged, the luminaire shall be destroyed.
Caution, risk of electric shock.
Product in protection class I. All electrically conductive, metallic housing parts that can absorb voltage during operation or during maintenance in the event of a fault must be continuously connected to the protective earthing conductor.
Do not stare at the operating light source: The luminaire should be positioned so that prolonged staring into the luminaire at a distance closer that 4 m is not expected.

References / Links

Product code	Packaging unit (Pieces/Unit)	Dimensions (length x width x height)	Gross weight	Volume
4099854682346	Shipping box 1	642 mm x 457 mm x 194 mm	9897.00 g	56.92 dm³
