PPRO MR16 35 36 ° 6.3 W/2700 K GU5.3

Product benefits
  • Quick, simple and safe replacement without rewiring
  • Design, dimensions, luminous flux comparable to an incandescent or halogen lamp
  • Low maintenance costs thanks to long lifetime
  • No UV and near-IR radiation in the light beam
  • Stepless dimming
  • Very high dimmer compatibility, see also www.ledvance.com/dim
  • Compatible with many common conventional and electronic control gears (see also compatibility list)
  • Instant 100 % light, no warm-up time
  • Lower energy consumption than incandescent or halogen lamps
View all details
Product data sheet
Go to LEDVANCE successor product

PRODUCT DETAILS

Electrical data

Nominal wattage 6.3 W
Construction wattage 6.30 W
Nominal voltage 12 V
Operating mode 12V AC/DC
Claimed equiv. conventional lamp power 35 W
Nominal current 570 mA
Type of current AC/DC
Inrush current 9.6 A
Operating frequency 50/60 Hz
Mains frequency 50/60 Hz
Max. lamp number on MCB B10 A 25
Max. lamp number on MCB B16 A 40
Power factor λ 0.90

Photometrical data

Luminous intensity 620 cd
Luminous flux 355 lm
Nominal useful luminous flux 90° 355 lm
Luminous efficacy 56 lm/W
Lumen main.fact.at end of nom.life time 0.70
Light color (designation) Warm White
Color temperature 2700 K
Color rendering index Ra 97
Light color 927
Standard deviation of color matching ≤3 sdcm
Rated peak intensity 620 cd
Rated LLMF at 6,000 h 0.80
Flickering metric (Pst LM) 0.2
Stroboscope effect metric (SVM) 0.4

Light technical data

Beam angle 36 °
Warm-up time (60 %) ‹ 0.50 s
Starting time < 0.5 s

Dimensions & Weight

Overall length 46.00 mm
Diameter 51.00 mm
Maximum diameter 51 mm
Product weight 42.00 g

Temperatures & operating conditions

Ambient temperature range -20…+40 °C
Maximum temperature at tc test point 100 °C

Lifespan

Lifespan L70/B50 at 25 °C 40000 h
Number of switching cycles 100000
Lumen maintenance at end of service lifetime 0.70
Rated lamp survival factor at 6,000 h ≥ 0.90

Additional product data

Base (standard designation) GU5.3
Mercury content 0.0 mg

Capabilities

Dimmable Yes

Certificates & Standards

Energy efficiency class G 1)
Energy consumption 7.00 kWh/1000h
Type of protection IP20
Standards CE, EAC
Photobiological safety group acc. to EN62778 RG1

1) Energy efficiency class (EEC) on a scale of A (highest efficiency) to G (lowest efficiency)

Country-specific categorizations

Order reference LPMR16D3536 6,3

Energy labelling regulation data acc EU 2019/2015

Lighting technology used LED
Non-directional or directional DLS
Mains or non-mains NMLS
Light source cap-type (or other electric interface) GU5.3
Connected light source (CLS) No
Color-tuneable light source No
Envelope No
High luminance light source No
Anti-glare shield No
Correlated colour temperature type SINGLE_VALUE
Claim of equivalent power Yes
Length 46.00 mm
Height 51.00 mm
Width 51.00 mm
Chromaticity coordinate x 0.455
Chromaticity coordinate y 0.405
R9 Colour rendering index 1
Beam angle correspondence NARROW_CONE_90
Survival factor 0,9
Displacement factor 0.70
LED light source replaces a fluorescent light source No
EPREL ID 523031
Model number AC32718

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Quantity of precious metals Contains at least 10 mg
Quantity of rare earths Contains at least 1 mg
Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage Yes
List of substances of very high concern in concentrations greater than 0.1% in mass percentage Lead (7439-92-1)

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • Quick, simple and safe replacement without rewiring
  • Design, dimensions, luminous flux comparable to an incandescent or halogen lamp
  • Low maintenance costs thanks to long lifetime
  • No UV and near-IR radiation in the light beam
  • Stepless dimming
  • Very high dimmer compatibility, see also www.ledvance.com/dim
  • Compatible with many common conventional and electronic control gears (see also compatibility list)
  • Instant 100 % light, no warm-up time
  • Lower energy consumption than incandescent or halogen lamps
Areas of application
  • Shops and exhibition rooms
  • Domestic applications
  • Commercial applications
  • Accent lighting
  • Outdoor use in suitable outdoor luminaires only
Product features
  • LED alternative to low voltage halogen lamps
  • High color consistency: ≤ 3 SDCM
  • Dimmable
  • Base: GU5.3
  • Lamp made of glass
  • Excellent color rendering CRI > 97
  • Lifetime up to 40,000 h
