PARATHOM CLASSIC A

Choose your product version

40 4 W/2700 K E27

4W 827 Frosted E27

4W 840 Clear E27

4W 840 Frosted E27

6.5W 827 Frosted E27

6.5W 827 Clear E27

60 6.5 W/4000 K E27

6.5W 840 Frosted E27

6.5W 840 Clear E27

60 FR 7 W/2700 K B22d

60 CL 7 W/2700 K B22d

60 7 W/2700 K E27

60 7 W/2700 K E27

60 7 W/4000 K E27

75 7.5 W/2700 K E27

75 7.5 W/2700 K E27

7.5W 827 Clear E27

7.5W 827 Frosted E27

75 7.5 W/4000 K E27

75 7.5 W/4000 K E27

75 7.5 W/4000 K E27

7.5W 840 Frosted E27

100 10 W/2700 K E27

100 10 W/2700 K E27

11W 827 Frosted E27

100 11 W/2700 K E27

100 11 W/4000 K E27

11W 840 Clear E27

150 16 W/2700 K E27

150 16 W/4000 K E27

17W 827 Frosted E27

17W 840 Frosted E27

24W 827 Frosted E27

24W 840 Frosted E27

OVERVIEW

Product description Base (standard designation) Nominal wattage Nominal voltage Nominal lamp life time Nominal luminous flux Claimed equiv. conventional lamp power Beam angle Dimmable
P CLAS A 40 4 W/2700 K E27 E27 4 W 220…240 V 15000 h 470 lm 40 W 300 ° No
LED Classic A 40 P 4W 827 Frosted E27 E27 4 W 220…240 V 15000 h 470 lm 40 W 300 ° No
LED Classic A 40 Filament P 4W 840 Clear E27 E27 4 W 220…240 V 15000 h 470 lm 40 W 300 ° No
LED Classic A 40 P 4W 840 Frosted E27 E27 4 W 220…240 V 15000 h 470 lm 40 W 300 ° No
LED Classic A 60 P 6.5W 827 Frosted E27 E27 6.5 W 220…240 V 15000 h 806 lm 60 W 300 ° No
LED Classic A 60 Filament P 6.5W 827 Clear E27 E27 6.5 W 220…240 V 15000 h 806 lm 60 W 300 ° No
P CLAS A 60 6.5 W/4000 K E27 E27 6.5 W 220…240 V 15000 h 806 lm 60 W 300 ° No
LED Classic A 60 P 6.5W 840 Frosted E27 E27 6.5 W 220…240 V 15000 h 806 lm 60 W 300 ° No
LED Classic A 60 Filament P 6.5W 840 Clear E27 E27 6.5 W 220…240 V 15000 h 806 lm 60 W 300 ° No
P CLAS A 60 FR 7 W/2700 K B22d B22d 7 W 220…240 V 15000 h 806 lm 60 W 300 ° No
P CLAS A 60 CL 7 W/2700 K B22d B22d 7 W 220…240 V 15000 h 806 lm 60 W 300 ° No
P CLAS A 60 7 W/2700 K E27 E27 7 W 220…240 V 15000 h 806 lm 60 W 300 ° No
P RF CLAS A 60 7 W/2700 K E27 E27 7 W 220…240 V 15000 h 806 lm 60 W 300 ° No
P CLAS A 60 7 W/4000 K E27 E27 7 W 220…240 V 15000 h 806 lm 60 W 300 ° No
P CLAS A 75 7.5 W/2700 K E27 E27 7.5 W 220…240 V 15000 h 1055 lm 75 W 300 ° No
P CLAS A 75 7.5 W/2700 K E27 E27 7.5 W 220…240 V 15000 h 1055 lm 75 W 300 ° No
LED Classic A 75 Filament P 7.5W 827 Clear E27 E27 7.5 W 220…240 V 15000 h 1055 lm 75 W 300 ° No
LED Classic A 75 P 7.5W 827 Frosted E27 E27 7.5 W 220…240 V 15000 h 1055 lm 75 W 300 ° No
P CLAS A 75 7.5 W/4000 K E27 E27 7.5 W 220…240 V 15000 h 1055 lm 75 W 300 ° No
P CLAS A 75 7.5 W/4000 K E27 E27 7.5 W 220…240 V 15000 h 1055 lm 75 W 300 ° No
P CLAS A 75 7.5 W/4000 K E27 E27 7.5 W 220…240 V 15000 h 1055 lm 75 W 300 ° No
LED Classic A 75 P 7.5W 840 Frosted E27 E27 7.5 W 220…240 V 15000 h 1055 lm 75 W 300 ° No
P CLAS A 100 10 W/2700 K E27 E27 10 W 220…240 V 15000 h 1521 lm 100 W 300 ° No
P CLAS A 100 10 W/2700 K E27 E27 10 W 220…240 V 15000 h 1521 lm 100 W 300 ° No
LED Classic A 100 P 11W 827 Frosted E27 E27 11 W 220…240 V 15000 h 1521 lm 100 W 300 ° No
P CLAS A 100 11 W/2700 K E27 E27 11 W 220…240 V 15000 h 1521 lm 100 W 300 ° No
P CLAS A 100 11 W/4000 K E27 E27 11 W 220…240 V 15000 h 1521 lm 100 W 300 ° No
LED Classic A 100 Filament P 11W 840 Clear E27 E27 11 W 220…240 V 15000 h 1521 lm 100 W 320 ° No
P CLAS A 150 16 W/2700 K E27 E27 16 W 220…240 V 15000 h 2500 lm 150 W 330 ° No
P CLAS A 150 16 W/4000 K E27 E27 16 W 220…240 V 15000 h 2500 lm 150 W 330 ° No
LED Classic A 150 P 17W 827 Frosted E27 E27 17 W 220…240 V 15000 h 2452 lm 150 W 330 ° No
LED Classic A 150 P 17W 840 Frosted E27 E27 17 W 220…240 V 15000 h 2452 lm 150 W 330 ° No
LED Classic A 200 P 24W 827 Frosted E27 E27 24 W 220…240 V 15000 h 3452 lm 200 W 320 ° No
LED Classic A 200 P 24W 840 Frosted E27 E27 24 W 220…240 V 15000 h 3452 lm 200 W 320 ° No


LED Classic A 100 Filament P 11W 827 Clear E27

Product benefits
  • Lamps with innovative LED "filament" technology
  • Design, dimensions, luminous flux comparable to an incandescent or halogen lamp
  • Lower energy consumption than incandescent or halogen lamps
  • No UV and near-IR radiation in the light beam
  • Instant 100 % light, no warm-up time
View all details
Product data sheet
Go to LEDVANCE successor product

PRODUCT DETAILS

Electrical data

Nominal wattage 11 W
Construction wattage 11.00 W
Nominal voltage 220…240 V
Claimed equiv. conventional lamp power 100 W
Nominal current 80 mA
Type of current AC
Inrush current 9.5 A
Operating frequency 50…60 Hz
Mains frequency 50…60 Hz
Max. lamp number on MCB B10 A 18
Max. lamp number on MCB B16 A 23
Total harmonic distortion 110 %
Power factor λ > 0.50

Photometrical data

Luminous flux 1521 lm
Nominal useful luminous flux 90° 1521 lm
Luminous efficacy 138 lm/W
Lumen main.fact.at end of nom.life time 0.93
Light color (designation) Warm White
Color temperature 2700 K
Color rendering index Ra 80
Light color 827
Standard deviation of color matching ≤6 sdcm
Rated LLMF at 6,000 h 0.80
Flickering metric (Pst LM) 1.0
Stroboscope effect metric (SVM) 0.4

Light technical data

Beam angle 320 °
Warm-up time (60 %) ‹ 0.50 s
Starting time < 0.5 s

Dimensions & Weight

Overall length 105.00 mm
Diameter 60.00 mm
Maximum diameter 60 mm
Product weight 35.00 g

Temperatures & operating conditions

Ambient temperature range -20…+40 °C
Maximum temperature at tc test point 70 °C

Lifespan

Lifespan L70/B50 at 25 °C 15000 h
Number of switching cycles 100000
Lumen maintenance at end of service lifetime 0.93
Rated lamp survival factor at 6,000 h ≥ 0.90

Additional product data

Base (standard designation) E27
Mercury content 0.0 mg
Design / version Clear

Capabilities

Dimmable No

Certificates & Standards

Energy efficiency class D
Energy consumption 11.00 kWh/1000h
Type of protection IP20
Standards CE, EAC
Photobiological safety group acc. to EN62778 RG1

Country-specific categorizations

Order reference LEDPCLA100 11W/

Energy labelling regulation data acc EU 2019/2015

Lighting technology used LED
Non-directional or directional NDLS
Mains or non-mains MLS
Light source cap-type (or other electric interface) E27
Connected light source (CLS) No
Color-tuneable light source No
Envelope No
High luminance light source No
Anti-glare shield No
Correlated colour temperature type SINGLE_VALUE
Standby power not applicable
Networked standby power for CLS not applicable
Claim of equivalent power Yes
Length 105.00 mm
Height 60.00 mm
Width 60.00 mm
Chromaticity coordinate x 0.463
Chromaticity coordinate y 0.420
R9 Colour rendering index 1
Beam angle correspondence SPHERE_360
Survival factor 0.90
Displacement factor 0.70
LED light source replaces a fluorescent light source No
EPREL ID 1151043
Model number AC41124

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage No

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • Lamps with innovative LED "filament" technology
  • Design, dimensions, luminous flux comparable to an incandescent or halogen lamp
  • Lower energy consumption than incandescent or halogen lamps
  • No UV and near-IR radiation in the light beam
  • Instant 100 % light, no warm-up time
Areas of application
  • Perfect for decorative installations
  • Domestic applications
  • General illumination
  • Outdoor use in suitable outdoor luminaires only
Product features
  • Professional LED lamps for line voltage
  • Not dimmable
  • Lifetime up to 15,000 h
  • Beam angle: up to 300°
  • Lamp made of glass
  • Good quality of light; color rendering index Ra: ≥ 80; constant chromaticity
Safety advice
  • Do not touch the lamp if broken.
  • Must not be used if outer bulb is defective.
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4058075756540 Folding box
1		 60 mm x 60 mm x 111 mm 49.00 g 0.40 dm³
4058075756557 Shipping box
10		 315 mm x 131 mm x 126 mm 584.00 g 5.20 dm³
Declarations of conformity
LED lamp CL A/B/P FIL PDF (299 KB)
Product image: white background, diagonal
LED Classic A100 FIL C lear JPG (1.42 MB)
Product image: white background, upright
LED Classic A100 FIL C lear JPG (1.26 MB)
Product line drawing with letters
LED Classic A100 FIL C lear SVG (14.28 KB)
Product line drawing with numbers
LED Classic A100 FIL C lear SVG (16.33 KB)
Product line drawing - technical
LED Classic A100 FIL C lear SVG (10.69 KB)
Energy label
EL-4058075756540-AC411 24 PDF (21.23 KB)
Logos and pictos
D left SVG (1.8 KB)
Logos and pictos
D left BW SVG (1.07 KB)
Logos and pictos
D right SVG (1.77 KB)
Logos and pictos
D right BW SVG (1.07 KB)
Spectral power distribution
EPREL data spectral di agram PROF LEDr 2700K PNG (103.24 KB)
EAN SEG number STK number EFO number ELDAS number
4058075756540 8297940 4731855 3764925 941813710
