Zvolte verzi vašeho produktu
| Output phases | 3-fázový |
| Max. input power DC | 6.5 kW |
| Vstupní napětí DC | 600 V |
| MPP voltage | 150-850 V |
| Max. input current DC | 20 A |
| Max. input current DC per string input | 20 A |
| Max. input current DC per MPP tracker | 20 A |
| Max. short circuit current per MPPT | 30 A |
| Number of independent MPPT inputs | 2 |
| String connections per MPPT input | 1 |
| Nominal output power AC | 5 kW |
| Délka | 408 mm |
| Šířka | 237 mm |
| Výška | 638 mm |
| Váha výrobku | 32500.000 g |
| Integrated DC switch | Ano |
| Connection DC for battery | Ano |
| Vhodné pro nouzové napájení | Ano |
| Charging controller integrated | Ano |
| With data logging | Ano |
| Wireless | Ano |
| Display | Standard |
| Ethernet | Ano |
| Integrovaný transformátor | Ne |
| Typ zapojení | MC4-kompatibilní |
| Provozní rozsah teplot | -40…+60 °C 1) |
| Rozsah okolní teploty | -40…+60 °C |
| Venkovní aplikace | Ne |
| Druh ochrany | IP65 |
| Barva produktu | bílá |
1) > 45℃ snížení výkonu
| Maximální účinnost | 97.60 % |
| European efficiency | 97.00 % |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | Ne |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Ano |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Lead (7439-92-1) 1,3,5-Triazine-2,4,6-triamine (68649-66-1) Tetrabromobisphenol A (79-94-7) Dodecamethylcyclohexasiloxane [D6] (540-97-6) Bisphenol A (BPA) (80-05-7) |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Kód produktu | Jednotka balení (kusy/jednotku) | Rozměry (délka x šířka x výška) | Hrubá hmotnost | Objem |
|---|---|---|---|---|
| 4099854136689 | Shipping box 1 |
840 mm x 545 mm x 385 mm | 36500.00 g | 176.25 dm³ |
| EAN | Číslo STK |
|---|---|
| 4099854136689 | 8010091 |
