Choose your product version
| Product description |
|---|
| EBN-OS /230 |
| Nominal wattage | 0.60 W |
| Nominal voltage | 230 V |
| Mains frequency | 50/60 Hz |
| Device power loss | 0,6 W |
| Surge capability (L/N-Ground) | 2 kV |
| Surge capability (L-N) | 2 kV |
| Operating frequency | 50 Hz |
| Length | 58.00 mm |
| Width | 18.00 mm |
| Height | 88.00 mm |
| Product weight | 75.00 g |
| Casing material | Plastic |
| Body material | Plastic |
| Ambient temperature range | -10…+40 °C |
| Max.housing temperature in case of fault | 110 °C |
| Permitted rel. humidity during operation | 5…85 % 1) |
1) Maximum 56 days/year at 85 %
| Dimmable | No |
| Overheating protection | Automatic switch off, reversible by manual mains reset |
| Type of installation | 35 mm standard rail |
| Standards | Acc. to IEC 801-4 level 4, Acc. to IEC 801-5 level 3, Acc. to VDE 0110 Gr C/250V |
| Protection class | 1 |
| Temperature range at storage | -40…+85 °C |
| Quantity of precious metals | 0 mg |
| Quantity of rare earths | 0 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4006584548019 | Unpacked 1 |
90 mm x 18 mm x 59 mm | 75.00 g | 0.10 dm³ |
| 4062172123259 | Folding box 10 |
| EAN | SEG number | EFO number |
|---|---|---|
| 4006584548019 | 7980344 | 3322041 |
