Choose your product version
| Product description |
|---|
| PL-CN 111AC-G2 1800-840 40 |
| Nominal wattage | 17.00 W |
| Construction wattage | 17.00 W |
| Nominal voltage | 230 V |
| Input voltage range | 220…240 V |
| Type of current | AC |
| Nominal current | 0.08 A |
| Power factor λ | ≥ 0.90 |
| Flickering metric (Pst LM) | ≤1 |
| Luminous efficacy | 117.4 lm/W |
| Luminous flux | 1655 lm 1) |
| Luminous intensity | 2900 cd |
| Color temperature | 3900 K |
| Color rendering index Ra | 80 |
| Light color LED | White |
| Light color (designation) | Neutral White |
| Standard deviation of color matching | 3 sdcm |
| Rated peak intensity | 2900 cd |
| Flickering metric (Pst LM) | ≤1 |
| Stroboscope effect metric (SVM) | ≤0.9 |
1) 90 °
| Beam angle | 40 ° |
| Starting time [PIM] | < 0.5 s |
| Number of LEDs per module | 18 |
| Length | 111.00 mm |
| Cable length | 500.000 |
| Width | 111.00 mm |
| Height | 49.50 mm |
| Diameter | 110.7 mm |
| Product weight | 340.00 g |
| Product color | White |
| Ambient temperature range | -25…80 °C |
| Maximum temperature at tc test point | 80 °C |
| Temperature range in operation | -25…80 °C |
| Performance temp. acc. to IEC 62717 | 65 °C |
| Nominal lamp life time | 35000 h |
| Number of switching cycles | 100000 |
| Dimmable | No |
| Standards | Acc. to IEC 62471, Acc. to IEC 60598-1, Acc. to EN 60529, Acc. to EN62031 IEC 605981, Acc. to EN 55015, Acc. to EN 61547 |
| Type of protection | IP20 |
| Energy efficiency class | E |
| Lighting technology used | LED |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4062172239431 | Folding box 1 |
129 mm x 118 mm x 64 mm | 380.00 g | 0.97 dm³ |
| 4062172239448 | Shipping box 12 |
280 mm x 254 mm x 224 mm | 4943.00 g | 15.93 dm³ |
