Choose your product version
| Nominal wattage | 15.50 W |
| Construction wattage | 15.50 W |
| Nominal voltage | 230 V |
| Input voltage range | 220…240 V |
| Type of current | AC |
| Nominal current | 75.000 mA |
| Power factor λ | ≥ 0.90 |
| Flickering metric (Pst LM) | ≤1 |
| Total useful luminous flux [PICOS] | 1250 lm |
| Luminous efficacy | 81 lm/W |
| Luminous flux | 1130 lm 1) |
| Luminous intensity | 4100 cd |
| Nom. useful luminous flux 120° [PICOS] | 1209 lm |
| Color temperature | 3100 K |
| Color rendering index Ra | 83 |
| Light color LED | White |
| Light color (designation) | Warm White |
| Standard deviation of color matching | 3 sdcm |
| Rated peak intensity | 4100 cd |
| Lumen main.fact.at end of nom.life time | 0.70 |
| Flickering metric (Pst LM) | ≤1 |
| Stroboscope effect metric (SVM) | ≤0.9 |
1) 90 °
| Beam angle | 24 ° |
| Rated beam angle (half peak value) | 24.00 ° |
| Number of LEDs per module | 12 |
| Cable length | 500.000 |
| Height | 50.00 mm |
| Diameter | 110.7 mm |
| Product weight | 340.00 g |
| Product color | White |
| Ambient temperature range | -40…80 °C |
| Maximum temperature at tc test point | 80 °C |
| Temperature range in operation | -40…80 °C |
| Performance temp. acc. to IEC 62717 | 68 °C |
| Nominal lamp life time | 35000 h |
| Number of switching cycles | > 100000 |
| Product remark |
For current photometric data and important safety, installation and application information, see |
| Dimmable | No |
| Standards | Acc. to EN 55015, Acc. to EN 61547, Acc. to EN 62031, Acc. to IEC 60598-1, Acc. to IEC 62471, CE, ROHS, UL-94 |
| Type of protection | IP20 |
| Energy consumption | 16.00 kWh/1000h |
| Energy efficiency class | F |
| Lighting technology used | LED |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Yes |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Lead (7439-92-1) |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4052899165533 | Folding box 1 |
110 mm x 40 mm x 40 mm | 380.00 g | 0.18 dm³ |
| 4052899165540 | Shipping box 12 |
280 mm x 254 mm x 224 mm | 5003.00 g | 15.93 dm³ |
