Product description	Nominal wattage	Number of switching cycles	Beam angle	Luminous flux	Dimmable
DP FLEX DA 1200 P 34W 830 IP66	34.00 W	100000	120 °	5500 lm	Yes
DP FLEX DA 1200 P 34W 840 IP66	34.00 W	100000	120 °	5600 lm	Yes
DP FLEX DA 1200 P 34W 865 IP66	34.00 W	100000	120 °	5600 lm	Yes
DP FLEX DA 1500 P 42W 830 IP66	42.00 W	100000	120 °	6800 lm	Yes
DP FLEX DA 1500 P 42W 840 IP66	42.00 W	100000	120 °	6900 lm	Yes
DP FLEX DA 1500 P 42W 865 IP66	42.00 W	100000	120 °	6900 lm	Yes

DP FLEX DA 1500 P 42W 865 IP66

Product benefits

High compatibility thanks to DALI-2 certification
Driver suitable for Emergency escape lighting systems acc. to EN 50172
Uniform light distribution
Easy upgradeability of light source and driver (EVERLOOP design)
Enables participation in funding programs in certain countries to replace light source and driver
Easy access to electrical terminal thanks to end caps with twist and lock mechanism
Easy installation as mounting brackets can be positioned freely on the luminaire
Tool-free electrical connection due to push button connector
Energy savings of up to 66 % (compared to luminaires that use fluorescent lamps)
Low flicker ≤ 3 %

View all details

Product data sheet

PRODUCT DETAILS

Technical data

Electrical data

Nominal wattage	42.00 W
Nominal voltage	220…240 V
Mains frequency	0/50/60 Hz
Nominal current	185.000 mA
Inrush current	3.6 A
Inrush current time T_h50	1800 µs
Max. number of luminaires per miniature circuit breaker B16	24
Max. number of luminaires per miniature circuit breaker C10	25
Max. number of luminaires per miniature circuit breaker C16	40
Power factor λ	> 0.90
Total harmonic distortion	≤ 23 %
Protection class	II
Operating mode	Integrated LED driver

Photometrical data

Luminous flux	6900 lm
Luminous efficacy	162 lm/W
Color temperature	6500 K
Light color (designation)	Cool Daylight
Color rendering index Ra	≥80
Standard deviation of color matching	≤5 sdcm
Low flicker	Yes
Flickering metric (Pst LM)	≤ 1
Stroboscope effect metric (SVM)	≤ 0.4
Photobiological safety group acc. to EN62778	RG0
Beam angle	120 °

Dimensions & Weight

Length	1620.00 mm
Height	73.00 mm
Width	88.00 mm
Product weight	1560.00 g

Materials & Colors

Product color	Gray
Housing color	Gray
Body material	Polycarbonate (PC)
Cover material	Polycarbonate (PC)
Light emitting surface material	Polycarbonate (PC)
Glow Wire Test according to IEC 60695-2-12	850 °C
Mercury content	0.0 mg

Application & Mounting

Ambient temperature range	-20…+50 °C
Temperature range at storage	-40…+80 °C
Type of connection	Screwless terminal, 5-Pole
Type of protection	IP66
Protection class IK (shock resistance)	IK08
Dimmable	Yes
Type of dimming	DALI2
Dimming range	1…100 %
IoT ready	Support of DALI data type PART 251, 252, 253 ¹⁾
Mounting type	Suspended/Surface
Mounting location	Ceiling
Application environment	Indoor
With light source	Yes
Replaceable light source	Yes

¹⁾ Internet of Things. Supports data transfer via gateway to cloud-based monitoring platforms, such as LEDVANCE VIVARES Cloud

Lifespan

Lifespan L70/B50 at 25 °C	100000 h ¹⁾
Lifespan L80/B10 at 25 °C	100000 h ¹⁾
Lifespan L90/B10 at 25 °C	61000 h
Number of switching cycles	100000

¹⁾ t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)

Control gear

Output current	75…400 mA
ECG - Output ripple current	< 2 %

Emergency lighting

Type of emergency operation test

None

Certificates & Standards

Standards	CE, CB, ENEC, TÜV SÜD, UKCA, EAC
Luminaire with limited surface temperature, "D sign"	Yes
Ball shot safe	No
Replaceable light source (EPREL)	By the end consumer

Additional product data

Product remark	When used in very cold applications as in cold storage, a special membrane might be required to ensure lifetime, Available from September 2025
Added function	EVERLOOP

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Minimum rate of recycled material in packaging	80 % ¹⁾
Minimum percentage of recycled content in the product	0 % ¹⁾
Product recyclability	Mostly recyclable product ¹⁾
Packaging recyclability	Mostly recyclable packaging ¹⁾
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage	No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage	Yes
List of substances of very high concern in concentrations greater than 0.1% in mass percentage	Lead (7439-92-1)

¹⁾ According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product description

Product benefits

High compatibility thanks to DALI-2 certification
Driver suitable for Emergency escape lighting systems acc. to EN 50172
Uniform light distribution
Easy upgradeability of light source and driver (EVERLOOP design)
Enables participation in funding programs in certain countries to replace light source and driver
Easy access to electrical terminal thanks to end caps with twist and lock mechanism
Easy installation as mounting brackets can be positioned freely on the luminaire
Tool-free electrical connection due to push button connector
Energy savings of up to 66 % (compared to luminaires that use fluorescent lamps)
Low flicker ≤ 3 %

Areas of application

Industrial and storage facilities
DALI installations
Workshops, assembly lines
Passages, underpasses
Parking garages
Underground parking

Product features

High luminous efficacy: up to 162 lm/W
Lifetime (L80/B10): up to 100,000 h (at 25 °C)
Housing and diffuser material: polycarbonate (PC)
Through-wiring 3x1.5mm² already installed
Beam angle: 120°
Protection rating: IP66
Impact resistance: IK08

Equipment / Accessories

Stainless steel clamps with safety screws included
Mounting accessories included (suspension kit, theft protection kit)
EVERLOOP luminaire: upgrades and replacements available

Safety advice

All electrical connections must be made by a qualified person.
Caution, risk of electric shock.

References / Links

For Guarantee see www.ledvance.com/guarantee

GTIN and Packaging information

Product code	Packaging unit (Pieces/Unit)	Dimensions (length x width x height)	Gross weight	Volume
4099854637766	Folding box 1	1,328 mm x 95 mm x 78 mm	1792.00 g	9.84 dm³
4099854637773	Shipping box 6	1,650 mm x 248 mm x 215 mm	12320.00 g	87.98 dm³

1200 P 34W 830 IP66

1200 P 34W 840 IP66

1200 P 34W 865 IP66

1500 P 42W 830 IP66

1500 P 42W 840 IP66

1500 P 42W 865 IP66
