Choose your product version
| Output phases | Single phase |
| Max. input power DC | 9.6 kW |
| Input voltage DC | 330 V |
| MPP voltage | 90 - 520 V |
| Max. input current DC | 16 A |
| Max. input current DC per string input | 16 A |
| Max. input current DC per MPP tracker | 16 A |
| Max. short circuit current per MPPT | 24 A |
| Number of independent MPPT inputs | 2 |
| String connections per MPPT input | 1 |
| Nominal output power AC | 6 kW |
| Length | 405 mm |
| Width | 205 mm |
| Height | 480 mm |
| Product weight | 24200.000 g |
| Integrated DC switch | Yes |
| Connection DC for battery | Yes |
| Suitable for emergency power | Yes |
| Charging controller integrated | Yes |
| With data logging | Yes |
| Wireless | Yes |
| Display | Standard |
| Ethernet | Yes |
| Integrated transformer | No |
| Type of connection | Staubli MC4 |
| Temperature range in operation | -25…+60 °C |
| Ambient temperature range | -25…+60 °C |
| Outdoor application | No |
| Type of protection | IP66 |
| Product color | White |
| Maximum efficiency | 97.50 % |
| European efficiency | 96.20 % |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4099854168178 | Shipping box 1 |
605 mm x 400 mm x 300 mm | 25448.00 g | 72.60 dm³ |
| EAN | STK number |
|---|---|
| 4099854168178 | 8010062 |
