Choose your product version
| Output phases | 3-phase |
| Max. input power DC | 32 kW |
| Input voltage DC | 600 V |
| MPP voltage | 200-850 V |
| Max. input current DC | 20 A |
| Max. input current DC per string input | 20 A |
| Max. input current DC per MPP tracker | 20 A |
| Max. short circuit current per MPPT | 30 A |
| Number of independent MPPT inputs | 4 |
| String connections per MPPT input | 1 |
| Nominal output power AC | 20 kW |
| Power consumption | <25 W |
| Length | 563 mm |
| Width | 546 mm |
| Height | 235 mm |
| Product weight | 32600.000 g |
| Integrated DC switch | Yes |
| Connection DC for battery | Yes |
| Suitable for emergency power | Yes |
| Charging controller integrated | Yes |
| With data logging | Yes |
| Wireless | Yes |
| Display | Standard |
| Ethernet | Yes |
| Integrated transformer | No |
| Type of connection | Staubli MC4 |
| Temperature range in operation | -25…+60 °C |
| Ambient temperature range | -25…+60 °C |
| Outdoor application | No |
| Type of protection | IP66 |
| Product color | White |
| Maximum efficiency | 98,50 % |
| European efficiency | 97,50 % |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Yes |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | 2-2Hbenzotriazol, 2-methyl, arsenic acid, barium chromate, Bis peroxide, Boric acid, bumetrizole (uv326), calcium arsenate, diarsenic pentaoxide, diarsenic trioxide, diboron trioxide, dioxobis(stearato), disodium octaborate, Disodium tetraborate, dodecamethylcyclohexasiloxane D6, fatty acids, Lead, Lead di(acetate), lead dinitrate, lead oxide sulfate, melamine, NN dimethylformaldehyde, orthoboric acid, sodium salt, Pthalato-2-dioxilead, silicic acid, lead salt, sulforous acid, tetraboron disodium, triethyl arsenate, trilead bis(carbonate), TRIPHENYL PHOSPLATE |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4099854438493 | Shipping box 1 |
645 mm x 695 mm x 343 mm | 33370.00 g | 153.76 dm³ |
