Output phases | Single phase |
Max. input power DC | 3.75 kW |
Input voltage DC | 250 V |
MPP voltage | 50 - 450 V |
Max. input current DC | 14 A |
Max. input current DC per string input | 14 A |
Max. input current DC per MPP tracker | 14 A |
Max. short circuit current per MPPT | 22 A |
Number of independent MPPT inputs | 2 |
String connections per MPPT input | 1 |
Nominal output power AC | 2.5 kW |
Power consumption | <1 W |
Length | 310 mm |
Width | 160 mm |
Height | 543 mm |
Product weight | 11000.000 g |
Integrated DC switch | Yes |
Connection DC for battery | No |
Suitable for emergency power | No |
Charging controller integrated | No |
With data logging | Yes |
Wireless | Yes |
Display | Standard |
Ethernet | Yes |
Integrated transformer | No |
Type of connection | Staubli MC4 |
Temperature range in operation | -25…+60 °C |
Ambient temperature range | -25…+60 °C |
Outdoor application | No |
Type of protection | IP66 |
Product color | White |
Maximum efficiency | 97.30 % |
European efficiency | 96.50 % |
Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
---|---|---|---|---|
4099854168185 | Shipping box 1 |
639 mm x 372 mm x 230 mm | 11943.00 g | 54.67 dm³ |
EAN | STK number |
---|---|
4099854168185 | 8010031 |
