Product description |
---|
LT 12K F2-DC-AFCI-WIET |
LT 15K F2-DC-AFCI-WIET |
LT 17K F2-DC-AFCI-WIET |
LT 20K F2-DC-AFCI-WIET |
Output phases | 3-phase |
Max. input power DC | 18 kW |
Input voltage DC | 600 V |
MPP voltage | 160 - 1000 V |
Max. input current DC | 32 A |
Max. input current DC per string input | 16 A |
Max. input current DC per MPP tracker | 32 A |
Max. short circuit current per MPPT | 40 A |
Number of independent MPPT inputs | 2 |
String connections per MPPT input | 2 |
Nominal output power AC | 12 kW |
Power consumption | <1 W |
Length | 310 mm |
Width | 219 mm |
Height | 563 mm |
Product weight | 17800.000 g |
Integrated DC switch | Yes |
Connection DC for battery | No |
Suitable for emergency power | No |
Charging controller integrated | No |
With data logging | Yes |
Wireless | Yes |
Display | Standard |
Ethernet | Yes |
Integrated transformer | No |
Type of connection | Staubli MC4 |
Temperature range in operation | -25…+60 °C |
Ambient temperature range | -25…+60 °C |
Outdoor application | No |
Type of protection | IP66 |
Product color | White |
Maximum efficiency | 98.60 % |
European efficiency | 98.00 % |
Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
---|---|---|---|---|
4099854168567 | Shipping box 1 |
644 mm x 384 mm x 326 mm | 18998.00 g | 80.62 dm³ |
EAN | STK number |
---|---|
4099854168567 | 8010044 |
