Output phases | 3-phase |
Max. input power DC | 37.5 kW |
Input voltage DC | 600 V |
MPP voltage | 200 - 1000 V |
Max. input current DC | 32 A |
Max. input current DC per string input | 16 A |
Max. input current DC per MPP tracker | 32 A |
Max. short circuit current per MPPT | 40 A |
Number of independent MPPT inputs | 3 |
String connections per MPPT input | 2 |
Nominal output power AC | 25 kW |
Power consumption | <1 W |
Length | 647 mm |
Width | 252 mm |
Height | 629 mm |
Product weight | 37000.000 g |
Integrated DC switch | Yes |
Connection DC for battery | No |
Suitable for emergency power | No |
Charging controller integrated | No |
With data logging | Yes |
Wireless | Yes |
Display | Standard |
Ethernet | Yes |
Integrated transformer | No |
Type of connection | Staubli MC4 |
Temperature range in operation | -25…+60 °C |
Ambient temperature range | -25…+60 °C |
Outdoor application | No |
Type of protection | IP66 |
Product color | White |
Maximum efficiency | 98.50 % |
European efficiency | 98.10 % |
Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
---|---|---|---|---|
4099854167683 | Shipping box 1 |
800 mm x 730 mm x 340 mm | 39671.00 g | 198.56 dm³ |
EAN | STK number |
---|---|
4099854167683 | 8010048 |
