LED CLASSIC A ENERGY EFFICIENCY A S

LED CLASSIC A ENERGY EFFICIENCY A S

Choose your product version

NEW

2.2W 827 Frosted E27

NEW

2.2W 827 Clear E27

2.2W 830 Clear E27

2.2W 830 Frosted E27

NEW

2.2W 840 Frosted E27

NEW

2.2W 840 Clear E27

2.5W 830 Clear E27

2.5W 830 Frosted E27

NEW

3.8W 827 Frosted E27

NEW

3.8W 827 Clear E27

3.8W 830 Frosted E27

3.8W 830 Clear E27

NEW

3.8W 840 Frosted E27

NEW

3.8W 840 Clear E27

4W 830 Clear E27

NEW

5W 827 Frosted E27

NEW

5W 827 Clear E27

5W 830 Clear E27

5W 830 Clear E27

5W 830 Frosted E27

5W 830 Frosted E27

NEW

5W 840 Clear E27

NEW

5W 840 Frosted E27

NEW

7.2W 827 Frosted E27

NEW

7.2W 827 Clear E27

7.2W 830 Frosted E27

7.2W 830 Clear E27

7.2W 830 Clear E27

7.2W 830 Frosted E27

NEW

7.2W 840 Clear E27

NEW

7.2W 840 Frosted E27

NEW

11.6W 827 Frosted E27

NEW

11.6W 840 Frosted E27

OVERVIEW

Product description Base (standard designation) Nominal wattage Nominal voltage Nominal lamp life time Nominal luminous flux Claimed equiv. conventional lamp power Beam angle Dimmable
LED Classic A 40 Filament Energy efficiency class A S 2.2W 827 Frosted E27 E27 2.2 W 220…240 V 50000 h 470 lm 40 W 300 ° No
LED Classic A 40 Filament Energy efficiency class A S 2.2W 827 Clear E27 E27 2.2 W 220…240 V 50000 h 470 lm 40 W 300 ° No
LED Classic A 40 Filament Energy efficiency class A S 2.2W 830 Clear E27 E27 2.2 W 220…240 V 50000 h 470 lm 40 W 320 ° No
LED Classic A 40 Filament Energy efficiency class A S 2.2W 830 Frosted E27 E27 2.2 W 220…240 V 50000 h 470 lm 40 W 320 ° No
LED Classic A 40 Filament Energy efficiency class A S 2.2W 840 Frosted E27 E27 2.2 W 220…240 V 50000 h 470 lm 40 W 320 ° No
LED Classic A 40 Filament Energy efficiency class A S 2.2W 840 Clear E27 E27 2.2 W 220…240 V 50000 h 470 lm 40 W 320 ° No
LED Classic A 40 Filament Energy efficiency class A S 2.5W 830 Clear E27 E27 2.5 W 220…240 V 50000 h 525 lm 40 W 300 ° No
LED Classic A 40 Energy efficiency class A S 2.5W 830 Frosted E27 E27 2.5 W 220…240 V 50000 h 525 lm 40 W 300 ° No
LED Classic A 60 Filament Energy efficiency class A S 3.8W 827 Frosted E27 E27 3.8 W 220…240 V 50000 h 806 lm 60 W 300 ° No
LED Classic A 60 Filament Energy efficiency class A S 3.8W 827 Clear E27 E27 3.8 W 220…240 V 50000 h 806 lm 60 W 300 ° No
LED Classic A 60 Filament Energy efficiency class A S 3.8W 830 Frosted E27 E27 3.8 W 220…240 V 50000 h 806 lm 60 W 320 ° No
LED Classic A 60 Filament Energy efficiency class A S 3.8W 830 Clear E27 E27 3.8 W 220…240 V 50000 h 806 lm 60 W 320 ° No
LED Classic A 60 Filament Energy efficiency class A S 3.8W 840 Frosted E27 E27 3.8 W 220…240 V 50000 h 806 lm 60 W 320 ° No
LED Classic A 60 Filament Energy efficiency class A S 3.8W 840 Clear E27 E27 3.8 W 220…240 V 50000 h 806 lm 60 W 320 ° No
LED Classic A 60 Filament Energy efficiency class A S 4W 830 Clear E27 E27 4 W 220…240 V 50000 h 840 lm 60 W 300 ° No
LED Classic A 75 Filament Energy efficiency class A S 5W 827 Frosted E27 E27 5 W 220…240 V 50000 h 1055 lm 75 W 300 ° No
LED Classic A 75 Filament Energy efficiency class A S 5W 827 Clear E27 E27 5 W 220…240 V 50000 h 1055 lm 75 W 300 ° No
LED Classic A 75 Filament Energy efficiency class A S 5W 830 Clear E27 E27 5 W 220…240 V 50000 h 1055 lm 75 W 320 ° No
LED Classic A 75 Filament Energy efficiency class A S 5W 830 Clear E27 E27 5 W 220…240 V 50000 h 1055 lm 75 W 300 ° No
LED Classic A 75 Filament Energy efficiency class A S 5W 830 Frosted E27 E27 5 W 220…240 V 50000 h 1055 lm 75 W 320 ° No
LED Classic A 75 Energy efficiency class A S 5W 830 Frosted E27 E27 5 W 220…240 V 50000 h 1055 lm 75 W 300 ° No
LED Classic A 75 Filament Energy efficiency class A S 5W 840 Clear E27 E27 5 W 220…240 V 50000 h 1055 lm 75 W 320 ° No
LED Classic A 75 Filament Energy efficiency class A S 5W 840 Frosted E27 E27 5 W 220…240 V 50000 h 1055 lm 75 W 320 ° No
LED Classic A 100 Filament Energy efficiency class A S 7.2W 827 Frosted E27 E27 7.2 W 220…240 V 50000 h 1521 lm 100 W 300 ° No
LED Classic A 100 Filament Energy efficiency class A S 7.2W 827 Clear E27 E27 7.2 W 220…240 V 50000 h 1521 lm 100 W 300 ° No
LED Classic A 100 Energy efficiency class A S 7.2W 830 Frosted E27 E27 7.2 W 220…240 V 50000 h 1521 lm 100 W 300 ° No
LED Classic A 100 Filament Energy efficiency class A S 7.2W 830 Clear E27 E27 7.2 W 220…240 V 50000 h 1521 lm 100 W 300 ° No
LED Classic A 100 Filament Energy efficiency class A S 7.2W 830 Clear E27 E27 7.2 W 220…240 V 50000 h 1521 lm 100 W 320 ° No
LED Classic A 100 Filament Energy efficiency class A S 7.2W 830 Frosted E27 E27 7.2 W 220…240 V 50000 h 1521 lm 100 W 320 ° No
LED Classic A 100 Filament Energy efficiency class A S 7.2W 840 Clear E27 E27 7.2 W 220…240 V 50000 h 1521 lm 100 W 320 ° No
LED Classic A 100 Filament Energy efficiency class A S 7.2W 840 Frosted E27 E27 7.2 W 220…240 V 50000 h 1521 lm 100 W 320 ° No
LED Classic A 150 Filament Energy efficiency class A S 11.6W 827 Frosted E27 E27 11.6 W 220…240 . V 50000 h 2452 lm 150 W 330 ° No
LED Classic A 150 Filament Energy efficiency class A S 11.6W 840 Frosted E27 E27 11.6 W 220…240 . V 50000 h 2452 lm 150 W 330 ° No
NEW


LED Classic A 40 Filament Energy efficiency class A S 2.2W 827 Frosted E27

Product benefits
  • Lamps with innovative LED "filament" technology
  • Low energy consumption
  • Design, dimensions, luminous flux comparable to a halogen lamp
  • Instant 100 % light, no warm-up time
  • Low flickering
View all details
Product data sheet

PRODUCT DETAILS

Electrical data

Nominal wattage 2.2 W
Construction wattage 2.20 W
Nominal voltage 220…240 V
Operating mode AC Mains
Claimed equiv. conventional lamp power 40 W
Nominal current 20 mA
Type of current AC
Inrush current 1.44 A
Operating frequency 50/60 Hz
Mains frequency 50/60 Hz
Max. lamp number on MCB B10 A 151
Max. lamp number on MCB B16 A 180
Total harmonic distortion 102.30 %
Power factor λ 0.46

Photometrical data

Luminous flux 470 lm
Luminous efficacy 213 lm/W
Lumen main.fact.at end of nom.life time 0.96
Light color (designation) Warm White
Color temperature 2700 K
Color rendering index Ra 80
Light color 827
Standard deviation of color matching ≤6 sdcm
Flickering metric (Pst LM) ≤1
Stroboscope effect metric (SVM) ≤0.4

Light technical data

Beam angle 300 °
Warm-up time (60 %) ‹ 0.50 s
Starting time < 0.5 s

Dimensions & Weight

Overall length 105.00 mm
Diameter 60.00 mm
Maximum diameter 60 mm
Product weight 31.00 g

Temperatures & operating conditions

Ambient temperature range -20…+40 °C
Maximum temperature at tc test point ≤ 50 °C

Lifespan

Lifespan L70/B50 at 25 °C 50000 h
Number of switching cycles 500000
Lumen maintenance at end of service lifetime 0.96

Additional product data

Base (standard designation) E27
Mercury content 0.0 mg
Mercury-free Yes
Design / version Frosted
Product remark All technical parameters apply to the entire lamp, Due to the complex production process for light-emitting diodes, the typical values shown for the technical LED parameters are purely statistical values that do not necessarily match the actual technical parameters of each individual product, which can vary from the typical value

Capabilities

Dimmable No

Certificates & Standards

Energy efficiency class A 1)
Energy consumption 3.00 kWh/1000h
Type of protection IP20
Standards CE, UKCA, EAC
Photobiological safety group acc. to EN62778 RG1

1) Energy efficiency class (EEC) on a scale of A (highest efficiency) to G (lowest efficiency)

Country-specific categorizations

Order reference LEDCLA40EELA 2.

LOGISTICAL DATA

Temperature range at storage -20…+80 °C

Energy labelling regulation data acc EU 2019/2015

Lighting technology used LED
Non-directional or directional NDLS
Mains or non-mains MLS
Light source cap-type (or other electric interface) E27
Connected light source (CLS) No
Color-tuneable light source No
Envelope No
High luminance light source No
Anti-glare shield No
Correlated colour temperature type SINGLE_VALUE
Standby power 0 W
Claim of equivalent power Yes
Length 105.00 mm
Height 60.00 mm
Width 60.00 mm
Chromaticity coordinate x 0.463
Chromaticity coordinate y 0.420
R9 Colour rendering index 24
Beam angle correspondence SPHERE_360
Survival factor 0.9
Displacement factor 0.655
LED light source replaces a fluorescent light source No
EPREL ID 1838157,2185125
Model number AC57875,AC57875,AC69988

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Quantity of precious metals Contains at least 10 mg
Quantity of rare earths Contains at least 1 mg
Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage Additional info can be provided per individual request
List of substances of very high concern in concentrations greater than 0.1% in mass percentage

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • Lamps with innovative LED "filament" technology
  • Low energy consumption
  • Design, dimensions, luminous flux comparable to a halogen lamp
  • Instant 100 % light, no warm-up time
  • Low flickering
Areas of application
  • Perfect for decorative installations
  • Domestic applications
  • General illumination
  • Outdoor use in suitable outdoor luminaires only
Product features
  • LED lamps for line voltage
  • Luminous efficacy: up to 210 lm/W
  • Beam angle: up to 300°
  • Very long lifetime of up to 50,000 h
  • Very high number of switching cycles: 500,000
Safety advice
  • Do not touch the lamp if broken.
  • Must not be used if outer bulb is defective.
References / Links
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4099854236556 Folding box
1		 60 mm x 60 mm x 145 mm 46.00 g 0.52 dm³
4099854245428 Shipping box
10		 315 mm x 131 mm x 126 mm 544.00 g 5.20 dm³
Declarations of conformity
LED Lamp PDF (293.19 KB)
Product image: white background, diagonal with LEDVANCE logo
LED CLASSIC A FIL FR E 27 JPG (1.12 MB)
Product image: white background, diagonal
LED CLA GL FR E27 JPG (1.13 MB)
Product image: white background, upright LEDVANCE logo
LED CLASSIC A FIL FR E 27 JPG (1.08 MB)
Product image: white background, upright
LED CLA GL FR E27 JPG (1.06 MB)
Product line drawing with letters
LED CLASSIC A 40/60/7 5 /100 EEL A GL FR E27 SVG (8.54 KB)
Product line drawing with numbers
LED CLASSIC A 40/60/7 5 /100 EEL A GL FR E27 SVG (26.92 KB)
Product line drawing - technical
LED CLASSIC A 40/60/7 5 /100 EEL A GL FR E27 SVG (4.67 KB)
Combo Shot = Product Beauty Shot + Packaging Image
FC1 LED CLA 40 SUP ULT RA EFFICIENT 2.2W 827 GLFR E27 JPG (908.23 KB)
Packaging image, frontal
FC1 LED CLA 40 SUP ULT RA EFFICIENT 2.2W 827 GLFR E27 JPG (667.42 KB)
Packaging image, spacial
FC1 LED CLA 40 SUP ULT RA EFFICIENT 2.2W 827 GLFR E27 JPG (923.84 KB)
Energy label
EL-4099854236556-AC578 75 PDF (21.58 KB)
Energy label
EL-4099854236556-AC699 88 PDF (21.78 KB)
Logos and pictos
A left SVG (1.83 KB)
Logos and pictos
A left BW SVG (1.07 KB)
Logos and pictos
A right SVG (1.8 KB)
Logos and pictos
A right BW SVG (1.07 KB)
Spectral power distribution
Spectral graph classic A EDISON Globe 2700K JPG (179.15 KB)
EAN SEG number STK number
4099854236556 8299638 4737585
