Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| LN UO DA 600 P 21W CS WT | 21.00 W | 100000 | 130 ° | 3062 lm / 3101 lm / 2979 lm | No |
| LN UO DA 1200 P 27W CS WT | 27.00 W | 100000 | 110 ° | 4050 lm / 3780 lm | Yes |
| LN UO DA 1500 P 48W CS WT | 48.00 W | 100000 | 110 ° | 7200 lm / 6720 lm | Yes |
| Nominal wattage | 48.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 210 mA |
| Inrush current | 17 A |
| Inrush current time Th50 | 250 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 15 |
| Max. number of luminaires per miniature circuit breaker C10 | 14 |
| Max. number of luminaires per miniature circuit breaker C16 | 23 |
| Power factor λ | > 0.90 |
| Total harmonic distortion | < 15 % |
| Protection class | I |
| Operating mode | Integrated LED driver |
| Luminous flux | 7200 lm / 6720 lm |
| Luminous efficacy | 150 lm/W / 140 lm/W |
| Color temperature | 3000 K / 4000 K |
| Light color (designation) | Warm White, Cool White |
| Color rendering index Ra | > 80 |
| Standard deviation of color matching | < 3 sdcm |
| Low flicker | Yes |
| Flickering metric (Pst LM) | <1 |
| Stroboscope effect metric (SVM) | < 0.4 |
| Photobiological safety group acc. to EN62778 | RG0 |
| Beam angle | 110 ° |
| Nominal wattage | Color temperature | Luminous flux | Luminous efficacy |
|---|---|---|---|
| 48 W | 4000 K | 7200 lm | 150 lm/W |
| 48 W | 3000 K | 6720 lm | 140 lm/W |
| Length | 1458.00 mm |
| Height | 74.00 mm |
| Width | 65.00 mm |
| Product weight | 1500.00 g |
| Product color | White |
| Housing color | White |
| Body material | Steel |
| Cover material | Polycarbonate (PC) |
| Light emitting surface material | Polycarbonate (PC) |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+40 °C |
| Temperature range at storage | -40…+80 °C |
| Type of connection | Screwless terminal, 5-Pole (L, N, PE, DA+, DA-) |
| Type of protection | IP20 |
| Protection class IK (shock resistance) | IK08 |
| Dimmable | Yes |
| Type of dimming | DALI2 |
| Dimming range | 1…100 % |
| Mounting type | Surface |
| Mounting location | Ceiling, Wall |
| Adjustable | No |
| With light source | Yes |
| Replaceable light source | No |
| Lifespan L70/B50 at 25 °C | 88000 h 1) |
| Lifespan L80/B10 at 25 °C | 70000 h 1) |
| Number of switching cycles | 100000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Output current | 300 mA |
| ECG - Output ripple current | < 5 % |
| Recommended control gear | LF-FSD065YA |
| Type of emergency operation test | None |
| Standards | CE, CB, ENEC, UKCA, EAC |
| Luminaire with limited surface temperature, "D sign" | No |
| Ball shot safe | No |
| Replaceable light source (EPREL) | Not replaceable |
| Product remark | Available from September 2025 |
| Added function | MULTI SELECT |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075850415 | Folding box 1 |
69 mm x 1,464 mm x 77 mm | 1600.00 g | 7.78 dm³ |
| 4058075850422 | Shipping box 6 |
1,474 mm x 225 mm x 170 mm | 10350.00 g | 56.38 dm³ |
