Choose your product version
| Maximum Power Pmax (STC) | 660 W |
| Maximum Power Current Imp (STC) | 17.45 A |
| Short Circuit Current Isc (STC) | 18.50 A |
| Maximum Power Voltage Vmp (STC) | 37.83 V |
| Open Circuit Voltage Voc (STC) | 45.64 V |
| Module efficiency factor (STC) | 21.24 % |
| Maximum Power Pmax (NMOT) | 499 W |
| Maximum Power Current Imp (NMOT) | 14.28 A |
| Short Circuit Current Isc (NMOT) | 15.14 A |
| Maximum Power Voltage Vmp (NMOT) | 34.95 V |
| Open Circuit Voltage Voc (NMOT) | 42.45 V |
| Power tolerance | 3 % |
| Number of cells | 132 |
| Cell material | Mono crystalline |
| Number of bypass diodes | 3 |
| With frame | Yes |
| Type of connection | Staubli MC4 EVO2 |
| Width | 1303 mm |
| Length | 2384 mm |
| Height | 35 mm |
| Product weight | 32900.000 g |
| Cable length | 1.4 m |
| Glass with anti-reflection coating | Yes |
| Colour backsheet | White |
| Colour cells | Dark blue |
| Colour frame | Black |
| Front Glass | Yes |
| Nominal operating cell temperature | 44 °C |
| Temperature coefficient Isc | 0.040 %/K |
| Temperature coefficient Pmpp | -0.340 %/K |
| Temperature coefficient Uoc | -0.250 %/K |
| Maximum series fuse rating | 30 A |
| Maximum voltage | 1500 V |
| Temperature range in operation | -40…+85 °C |
| Front Side Maximum Static Loading | 5400 Pa |
| Rear Side Maximum Static Loading | 2400 Pa |
| Reverse current load | 30 A |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075836006 | Shipping box 31 |
1,350 mm x 1,130 mm x 2,400 mm | 1039900.00 g | 3661.20 dm³ |
| EAN | STK number |
|---|---|
| 4058075836006 | 8010030 |
